Home > Products > Led Street light > LM-ST-E

LM-ST-E

Product Item : LM-ST-E100
Category： Led Street light
APPLICATION:STREET
BODY:DIE CAST ALUMINUM
FINISH:SURFACE ANTI-AGEING ELECTROSTATIC SPRAY PROCESSING,SUPER RESISTANCE TO CORROSION
COLOR TEMPERATURE:3000-6500K
Product description：Simple modern design, user-friendly installation and easy maintenance structure, modular product portfolio planning, professional and reasonable optical design for road, expressway,bridge and square.
Order online

LEDS				EPISTAR 3030 & Luxeon 5050
Color rendering index				NW: 70. WW: 80
Initial LED luminaire efficacy				Up to130 lm/W (depending on the version)
Luminous flux tolerance				+-7%
Correlated Color Temperature				Warm white (WW): 3000 K Neutral white (NW): 4000 K Cool white(CW) :5700K
Lumen maintenance at median useful life* 100000 h				min L80 up to L95
Temperature of Working Condition				-40-50℃
Ingress protection code				IP66
Driver				Philips Xitanium / Meanwell ELG HLG XLG upon on request
Mains voltage				AC220-240V 50/60HZ
Power Factor				PF≥0.95
Power Tolerance				+-11%
Control gear failure rate at median useful life 100000 h				0.1
Surge protection				>10kv
Dimming				upon request for 0-10V Dali
Mech. impact protection code				IK08
